Hi-Vis Step Ballast Blocks for support with Temporary Fencing.
The Hi-Vis Step Ballast Block is used in conjunction with Anti-Climb Mesh Fence Panels to further stabilise fencing in high-wind areas and prevent the risk of fences falling. When filled with concrete, the ballast blocks enable fencing to withstand speeds of up to 41.8mph! They’re a better alternative to concrete ballasts that easily break, crack, chip, and cause tripping hazards, and bags of sand that split and lose ballast over time.
Manufactured from UV-resistant Medium Density Polyethylene (MDPE) to be long-lasting with a high-visibility yellow colour to maximise visibility in all weathers.
The Hi-Vis Step Ballast Block is easily installed by placing it over the feet of a fence panel and can be stacked to provide further fencing support to increase wind loading performance but also to save storage space when not in use!
Available as either water fillable 22kg (when filled) or supplied as concrete filled 44kg and reduces carbon footprint on-site.
Additional support including step block struts are available on request.
For a more heavy duty water-filled version, please take a look at our Hi-Vis Ballast Block.
Need to knows
It is the users responsibility to assess whether the site is capable of safety.
A water source is required.
Elite GSS Ltd accepts no liability whatsoever from any damage, loss or injury arising from the installation and ground conditions on which these products are used.
We help to obtain the right solution for your purpose
Whether you are unsure this product is right for the job or you need to choose something specific for the purpose, we can often offer additional solutions out of our extensive range.
Suitable industries and applications
Building Sites
Construction Sites
Festivals & Outdoor Events
Civil Engineering
Size:
609mm [W] x 295mm [H] x 300mm [D]
Weight:
22Kg when filled with water, 44Kg when filled with concrete (approx.)
Material:
UV-resistant Medium Density Polyethylene (MDPE)
Colour:
Hi-visibility yellow
Functionality
- Improved fencing structure stability and wind resistance
- Stackable for increased resistance
- Reduced overall carbon footprint
Connectivity
No connection systems are needed, simply place the Hi-Vis Step Ballast Block over the foot and fill with water or concrete.
Handling & Storage
Gloves should be worn when handling this product. We deliver to site in pre-wrapped packs with pallets incorporated and banded with polyester strips, to safely transport and store using mechanical equipment. This may vary for some products.
